Ancho de procesamiento: 600 mm, 800 mm, 1000 mm, 1300 mm, 1600 mm
Processing thickness: 0.5-100mm

Método de adsorción de la mesa de trabajo de alimentación:

• Potente adsorción magnética permanente (tamaño mínimo de pieza de trabajo 220*20 mm)
• Adsorción al vacío (tamaño mínimo de pieza de trabajo 250*50 mm)
• Adsorción semimagnética y semivacío.

Automatic thickness setting device: Four-column linkage synchronous lifting, motorized lifting with an accuracy of ±0.01mm

Processing speed:

• Velocidad del transportador: 0,3 m-9 m/min (frecuencia variable ajustable)
• Velocidad lineal de la rueda de alambre: 5 m/s-20 m/s (frecuencia variable ajustable)

Control PLC completo de la máquina con ajuste de parámetros de pantalla táctil

Equipped with wet industrial dust collector and flame-retardant dust collector for safe and environmentally friendly dust processing.

Features

1. 1) Deburring and fillet finishing of internal and external contour. Because it is flexible processing, all the sheet metal parts
   that have been polished, brushed and coated will not hurt the surface and film coating.
   2) It is suitable for removing burrs in the holes of flat or relatively the same flat sheet metal parts processed by CNC punching
   and shearing machines; Removal of burr after laser cutting; Flame cutting or plasma cutting slag removal.
   3) Instead of burr, use file, scraper or electric and pneumatic tools for grinding process, so that the workpiece is polished more
   evenly; Safer, and effectively reduce labor costs and improve production efficiency.
   4) Visual adjustment of grinding and stroke parameters, can only grind the workpiece contour and sharp edge without damaging the
   surface, effectively protect the coating of the workpiece, suitable for galvanized plate, coated aluminum plate, copper plate,
   stainless steel plate and other surface requirements of the protection of the workpiece.
   5) Turbo vacuum adsorption technology is adopted to ensure that the workpiece is firmly adsorbed during grinding, and the
   workpiece and shaped workpiece can also be adsorbed and polished after bending, greatly improving the processing range and
   efficiency, and preventing pressure loss or failure of the vacuum adsorption system due to blockage. More special magnetic suction
   system, when the workpiece is conditional to use magnetic adsorption fixed, greatly reduce the power consumption of equipment,
   energy saving and environmental protection, the maximum cost of production savings.
   6) The equipment adopts Delta PLC control system, easy to operate, convenient to adjust the grinding amount.
   7) If disk adsorption is selected for the product type, the power consumption of the device will be greatly reduced.
   The machine uses common consumables in the market, and can also be customized imported sand wheel to improve production efficiencyand to meet the special requirements of products.

Aplicaciones del equipo:

• Solución para desbarbado de piezas de corte por láser, punzonado y oxicorte.
• Acabado de redondeo de bordesPulido fino
• Pulido de la línea del cabello
