This model for polishing vertical tank welding seam. It is equipped with two sets of grinding head, welding seams can be polished at the same time. Inside grinding head equipped camera for easy operation. Grinding head move speed can be adjusted by frequency inverter. Grinding head can be exchanged.
| Outer Dimension | 5500*5000*4300 mm |
| Machine Weight | 3000 kg |
| Input Power | 10 KW |
| Control System | PLC |
| Produce Efficiency | 6 – 12 m2/h |
| Polishing Material | Abrasive belt, Flap wheel, Cloth wheel |
| Work Piece Dimension | Diameter : 750 – 4500 mm |
| Height : 2000 mm | |
| Max. Loading | 5T |
